3BDH000011R1 | ABB SA801F Analog Input Module
Description
General Information
Product ID:
57160001-ADF
ABB Type Designation:
DSDP 170
Catalog Description:
DSDP 170 inc. Pos. and Speed meas.
Long Description:
DSDP 170 Pulse Counting Board inc. Pos. and
Speed meas. which is primarily intended for
positioning/length and speed/frequency measuring.
Maximum pulse frequency is 2.5 MHz.
Note! This part is exempted from the scope of 2011/65/EU (RoHS)
as provided in Article 2(4)(c), (e), (f) and (j) therein
(ref.: 3BSE088609 – EU DECLARATION OF CONFORMITY
- ABB Advant Master Process Control System)
Additional Information
Medium Description:
Pulse Counting Board
Product Type:
I-O_Module
Technical Information:
DSDP 170 Pulse Counting Board inc. Pos. and
Speed meas. which is primarily intended for
positioning/length and speed/frequency measuring.
Maximum pulse frequency is 2.5 MHz.
Ordering
HS Code:
853890-- Parts suitable for use solely or principally with the apparatus of heading 85.35, 85.36 or 85.37.- Other
Customs Tariff Number:
85389091
Dimensions
Product Net Depth / Length:
328.5 mm
Product Net Height:
18 mm
Product Net Width:
238.5 mm
Product Net Weight:
0.38 kg
Environmental
RoHS Status:
Following EU Directive 2011/65/EU
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
Number of Batteries:
0
SCIP:
cbfb0250-ebbc-4494-b22e-ad36beae8e99 Sweden
Products
Products›Control System Products›I/O Products›S100 I/O›S100 I/O - Modules›DSDP 170 Pulse Inputs›DSDP 170 Pulse Input
Products›Control Systems›Advant OCS with Master SW›Controllers›Advant Controller 450›Advant Controller 450 Version 2.3›I/O Modules
Parts
Parts & Services›Control Systems›800xA›I/Os›S100 I/O›I/O Modules
Parts & Services›Control Systems›Advant OCS with Master SW›Controllers›MasterPiece 200 and 200/1›I/O Modules
Parts & Services›Control Systems›Advant OCS with Master SW›I/Os›S100 I/O›I/O Modules
Parts & Services›Control Systems›Advant OCS with MOD 300 SW›I/Os›S100 I/O›I/O Modules
Parts & Services›Control Systems›Compact Product Suite›I/Os›S100 I/O›I/O Modules
